| PN10/PN16 - HRK-8900 - DN300 - DN1200 |
| Applications |
| Hot and cold water systems, non-acidic and non-flammable liquid fluids. |
| Standards |
| Design | : | EN 12334 |
| Face to face dimensions | : | EN 558-1 Series 14 (DIN 3202 F4) |
| Flange Dimensions | : | EN 1092 - 2 |
| Part Name | Material |
| Body | : | Ductile Iron, GJS-400.15 / GJS-500.7, EN 1563 (GGG40 – 50, DIN 1693) |
| Disc | : | Ductile Iron, GJS-400.15 / GJS-500.7, EN 1563 (GGG40 – 50, DIN 1693) |
| Stem |
: | Stainless steel |
| Gasket | : | Epdm/Nbr/Viton |
| Coating |
: | Epoxy |
